| General | |
|---|---|
| Product Name | Zenmuse L1 |
| Dimensions | 152×110×169 mm |
| Weight | 930±10 g |
| Power | Typical: 30 W; Max: 60 W |
| IP Rating | IP54 |
| Supported Aircraft | Matrice 300 RTK |
| Operating Temperature | -20° to 50° C / 0° to 50° C (RGB) |
| Storage Temperature | -20° to 60° C |
| System Performance | |
| Detection Range | 450 m @ 80%, 190 m @ 10% |
| Point Rate | Single: 240,000 pts/s; Multiple: 480,000 pts/s |
| Accuracy (RMS 1σ) | Horizontal: 10 cm @ 50 m; Vertical: 5 cm @ 50 m |
| Point Cloud Coloring Modes | Reflectivity, Height, Distance, RGB |
| Lidar | |
| Ranging Accuracy | 3 cm @ 100 m |
| Maximum Returns Supported | 3 |
| Scan Modes | Non-repetitive, Repetitive |
| FOV | 70.4°×77.2° / 70.4°×4.5° |
| Laser Safety | Class 1 (Eye Safe) |
| Inertial Navigation | |
| IMU Update Frequency | 200 Hz |
| Accelerometer Range | ±8 g |
| Angular Velocity Range | ±2000 dps |
| Yaw Accuracy | Real-time: 0.3°, Post: 0.15° |
| Pitch/Roll Accuracy | Real-time: 0.05°, Post: 0.025° |
| Vision Sensor | |
| Resolution | 1280×960 |
| FOV | 95° |
| RGB Mapping Camera | |
| Sensor Size | 1 inch |
| Effective Pixels | 20 MP |
| Photo Sizes | 5472×3078, 4864×3648, 5472×3648 |
| Focal Length | 8.8 mm / 24 mm |
| Shutter Speed | 1/2000 - 8 s (Mech), 1/8000 - 8 s (Elec) |
| ISO | Video: 100–3200/6400, Photo: 100–12800 |
| Aperture | f/2.8 - f/11 |
| File System | FAT, exFAT |
| Photo Format | JPEG |
| Video Format | MOV, MP4 |
| Video Resolution | 4K: 3840×2160 30p |
| Gimbal | |
| Stabilization | 3-axis (tilt, roll, pan) |
| Angular Vibration Range | 0.01° |
| Mount | DJI SKYPORT |
| Mechanical Range | Tilt: -120° to +30°; Pan: ±320° |
| Modes | Follow, Free, Re-center |
| Data Storage | |
| Raw Data | Photo/IMU/Point cloud/GNSS/Calibration |
| Supported Cards | microSD UHS-I U3, 256 GB max |
| Recommended Cards | SanDisk Extreme, Lexar 1066x, Samsung EVO Plus |
| Post-processing Software | |
| Software | DJI Terra |
| Data Format | PNTS/LAS/PLY/PCD/S3MB |
DJI Zenmuse L1 Drone Camera Price in Bangladesh – Moharaz
The DJI Zenmuse L1 Drone Camera For Support is an advanced aerial imaging solution, combining a powerful LiDAR module, a 1-inch CMOS sensor camera, and a high-accuracy IMU. Designed for professional surveying and mapping, this camera system provides real-time 3D data, even in challenging environments. With a diagonal size of 247 mm and top speeds up to 16 m/s, it ensures rapid and stable flight. The 3-axis mechanical gimbal guarantees vibration-free footage, while the 48MP camera delivers exceptional imaging accuracy. Its max flight time of up to 47 minutes with the Intelligent Battery Plus offers extended operation for complex missions. Ideal for professionals who demand precision, durability, and performance, the Zenmuse L1 is supported with GPS, Galileo, and BeiDou systems for maximum location accuracy.
Features in DJI Zenmuse L1 Drone Camera For Support
- 1/1.3-inch CMOS sensor with 48MP resolution
- 3-axis gimbal stabilization for steady footage
- Max flight time up to 47 minutes
- Advanced GPS + Galileo + BeiDou positioning
- Real-time 3D data with LiDAR integration
- Max wind resistance of 10.7 m/s
- Operating range temperature from -10°C to 40°C
Features and Benefits
High-Resolution Imaging: Capture detailed visuals with a 48MP sensor and wide 82.1° FOV.
Advanced LiDAR Technology: Achieve precise 3D mapping and terrain modeling even in low-light conditions.
Reliable Flight Performance: With intelligent modes and wind resistance, ensure stable operation in dynamic environments.
Extended Battery Life: Fly up to 47 minutes with Intelligent Battery Plus for uninterrupted data collection.
Multi-Mode Operation: Choose from S, N, or C modes for different speeds and conditions.
Smart Remote Control: Operate with up to 8 km range via DJI O3 transmission system.
Durable & Efficient: Built for rugged tasks with industrial-grade materials and firmware stability.
DJI Zenmuse L1 Drone Camera price in Bangladesh
Get the updated DJI Zenmuse L1 Drone Camera price in Bangladesh for 2025. Ideal for mapping and surveying, order now at the best rate from authorized sellers.
Drone camera price in BD
Explore the latest drone camera price in BD and choose the best model for aerial photography or professional use. Great deals available online.
Bangladesh drone camera price in BD
Looking for the current Bangladesh drone camera price in BD? Check our store for competitive pricing and genuine products with warranty.
Drone camera price in BD 2025
Discover updated drone camera price in BD 2025 with advanced features for both hobbyists and professionals. Visit our site for the best offers today.
DJI drone camera price in BD
Find the latest DJI drone camera price in BD with original warranty and high-performance specs. Perfect for filming, surveillance, and creative projects.
Drone camera price in BD 2025
Check the top-rated drone camera price in BD 2025 for all your aerial needs. Buy now and enjoy nationwide delivery with trusted support.
Why Choose This Product?
The DJI Zenmuse L1 Drone Camera is the ideal choice for engineers, surveyors, and government projects needing high-precision data and imaging. With unmatched reliability, seamless integration with DJI platforms, and extended flight capabilities, it’s a future-ready solution for complex aerial mapping tasks. Moharaz ensures official warranty, top-level support, and competitive DJI Zenmuse L1 Drone Camera price in BD.Get more information of this product please visit official website.
FAQs
Q1: What is the maximum flight time of the DJI Zenmuse L1?
A1: With the Intelligent Flight Battery Plus, it can fly up to 47 minutes in windless conditions.
Q2: Is the DJI Zenmuse L1 suitable for professional mapping?
A2: Yes, it features LiDAR, a high-accuracy IMU, and a 48MP camera, ideal for aerial surveying and 3D mapping.
Q3: What is the warranty coverage for this product?
A3: The product comes with 1-year official service warranty (not valid if the drone is crashed).
